ATUC-IRCUDAN

The 19" rack-mountable ATUC-IRCUDAN control unit includes all the features of the ATUC-IRCU, plus a Dante™ output with redundancy. It enables the use of both infrared and wired discussion units, providing 24-bit/48 kHz digital signal processing (with 12-band feedback suppressor), automated gain control (AGC), mic gain and mic EQ for each connected discussion unit. The ATUC-IRCUDAN can be operated locally, through the Web Remote interface (no software required), or third-party IP control systems. The control unit offers three selectable conference modes (Free Talk, Request to Talk, and Full Remote) and various override settings.

• Crystal-clear, 24-bit digital audio processing with 12-band feedback suppressor
• Easy plug-and-play operation for wired, infrared, and hybrid discussion systems
• Each ATUC-IRCU infrared control unit supports a maximum of 200 ATUC-IRDU discussion units and 100 ATUC-50DU/IU units (use of ATLK-EXT165 link extenders may be required)
• Up to 500 microphones can be cascade-connected from the control unit (300 50DU units and 200 IRDU units)
• Systems can be configured in either daisy chain or ring topology
• Three selectable operation modes (Free Talk, Request to Talk, and Full Remote), plus various override settings
• Built-in WAV and MP3 recorder lets you record to a USB mass storage device
• Four configurable balanced matrix output plus one unbalanced output that outputs the same audio as Output 1
• Dante™ output with redundancy
• Two Mic/Line inputs, two AUX inputs, and two return inputs
• LED indicators on front panel allow for easy monitoring of critical system functions
• Front panel OLED displays active system information and presets
• Settings and operation can be handled locally at the control unit, through the Web Remote interface, or via third-party IP control systems
• Individual automated gain control (AGC), mic gain and mic EQ for each discussion unit
• Expandable and scalable system design
